Pole Mounted Area Light
Parking Lot Light
Wide-distribution LED area lights for parking facilities, retail plazas and logistics yards.
Technical Parameters
| Power | 100W / 150W / 200W / 300W |
|---|---|
| Luminous Efficiency | 145-175 lm/W |
| Input Voltage | 100-277VAC / 200-480VAC |
| CCT | 3000K / 4000K / 5000K |
| CRI | Ra70 / Ra80 optional |
| Beam Angle | Type III / Type IV / Type V |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Housing Material | Die-cast aluminum with PC lens |
| Working Temperature | -40 C to +50 C |
| Warranty | 5 years |
Features
Uniform distribution helps reduce dark zones
Photocell and 0-10V dimming options
Multiple pole adapters for retrofit projects
Durable finish for coastal and humid environments
Applications
Commercial parking lots
Logistics yards
Car dealerships
Campus parking
Mounting Options
Slip fitter
Square pole arm
Round pole arm
Trunnion mount
Datasheet package
Detailed datasheets, IES files and certification documents can be shared after confirming your market and project requirements.
Project Support
Need a custom lighting solution?
Share your target application, quantity and certification requirements. Our team will recommend a project-ready lighting package.
